Heap Sort is a comparison-based sorting algorithm that leverages a binary heap data structure to sort elements. It first builds a max heap from the input array, then repeatedly extracts the maximum element and places it at the end of the array. Heap Sort has a time complexity of O(n log n) and sorts in-place, making it memory-efficient, though it is not a stable sort.
Understanding the Problem
Heap Sort involves two main steps: building a heap from the array and then repeatedly removing the root of the heap to obtain a sorted sequence. Maintaining the heap property during extraction requires shifting elements appropriately, and incorrect indexing in the heap can break the sorting process. The algorithm works efficiently for large datasets due to its predictable O(n log n) performance.
Program: Heap Sort
This program demonstrates sorting an integer array in ascending order using Heap Sort.
#include <stdio.h>
// Function to swap two integers
void swap(int *a, int *b) {
int temp = *a;
*a = *b;
*b = temp;
}
// Heapify a subtree rooted at index i
void heapify(int arr[], int n, int i) {
int largest = i; // Initialize largest as root
int left = 2 * i + 1; // Left child index
int right = 2 * i + 2; // Right child index
// If left child is larger than root
if (left < n && arr[left] > arr[largest])
largest = left;
// If right child is larger than largest so far
if (right < n && arr[right] > arr[largest])
largest = right;
// If largest is not root
if (largest != i) {
swap(&arr[i], &arr[largest]);
// Recursively heapify the affected subtree
heapify(arr, n, largest);
}
}
// Heap Sort function
void heapSort(int arr[], int n) {
// Build max heap
for (int i = n / 2 - 1; i >= 0; i--)
heapify(arr, n, i);
// Extract elements from heap one by one
for (int i = n - 1; i >= 0; i--) {
swap(&arr[0], &arr[i]); // Move current root to end
heapify(arr, i, 0); // Heapify reduced heap
}
}
// Function to display array
void display(int arr[], int n) {
for (int i = 0; i < n; i++)
printf("%d ", arr[i]);
printf("\n");
}
int main() {
int arr[] = {12, 11, 13, 5, 6, 7};
int n = sizeof(arr)/sizeof(arr[0]);
printf("Original array: ");
display(arr, n);
heapSort(arr, n);
printf("Sorted array: ");
display(arr, n);
return 0;
}This program builds a max heap from the array and then repeatedly moves the largest element to the end while maintaining the heap property. The heapify function ensures that the subtree rooted at each index satisfies the max-heap condition.
FAQs
Q1: What is the time complexity of Heap Sort?
O(n log n) for best, average, and worst cases.
Q2: Is Heap Sort stable?
No, Heap Sort is not stable.
Q3: How much extra memory does Heap Sort require?
Heap Sort sorts in-place, requiring O(1) additional space.
Q4: When is Heap Sort preferred?
Heap Sort is useful for large datasets where memory efficiency is important and predictable O(n log n) performance is needed.
Conclusion
Heap Sort is a powerful in-place sorting algorithm that leverages the heap data structure to provide predictable O(n log n) performance. While not stable, its efficiency and memory advantage make it suitable for large datasets. Understanding Heap Sort also provides insight into binary heaps and priority queue operations.
